Description

The wire drawing machine is used to produce common low carbon steel wires,they are used into constuction fields,or weld all kinds of construction meshes,fence meshes,cage meshes,nail wires or other fields.

Diameter of the reel:Φ550mm

Drawing Time:6

Max inlet wire diameter:Φ6.5mm

Outlet wire diameter:Φ2.8-6.0mm

Inlet wire Strength:≤600mpa

The drawing speed:About 100-270m/min

Motor:15kw*6

Die size:Φ40mm*30

Reel Installing Way:Vertical

Mould Box:composed of powder box and  final two pulley equipped with water cooling box

Electric Control:Speed adjustable,

Frequency converter control:18.5KW*6

Including accessories:

Pointing machine  1set

Wire unloading device 1pcs

Wire drawing powder 2bags(80kgs)

Drawing wire moulds:6pcs(tungsten steel materail ,100% new)

Safe protection shield
